Table 5-1. Clock Summary
Clock name High Speed Run
mode
clock frequency
Run mode
clock frequency
VLPR mode
clock frequency
Clock source Clock is disabled
when…
MCGIRCLK or
OSCERCLK
5.5 Internal clocking requirements
The clock dividers are programmed via the SIM module’s CLKDIV registers. Each
divider is programmable from a divide-by-1 through divide-by-16 setting. The following
requirements must be met when configuring the clocks for this device:
1. The core and system clock frequencies must be 120 MHz or slower in HSRUN, 80
MHz or slower in RUN.
2. The bus clock frequency must be programmed to 60 MHz or less in HSRUN, 50
MHz or less in RUN, and an integer divide of the core clock. The core clock to bus
clock ratio is limited to a max value of 8.
3. The flash clock frequency must be programmed to 26.67 MHz or less, less than or
equal to the bus clock, and an integer divide of the core clock. The core clock to flash
clock ratio is limited to a max value of 8.
4. The FlexBus clock frequency must be programmed to be less than or equal to the bus
clock frequency. The FlexBus also has pad interface restrictions that limits the
maximum frequency. For this device the FlexBus maximum frequency is 30 MHz.
The core clock to FlexBus clock ratio is limited to a max value of 8.
The following are a few of the more common clock configurations for this device:
Option 1:
Clock Frequency
Core clock 50 MHz
System clock 50 MHz
Bus clock 50 MHz
FlexBus clock 25 MHz
Flash clock 25 MHz
Option 2: Run
Internal clocking requirements
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
156 NXP Semiconductors
