ADCx_OFS field descriptions (continued)
Field Description
OFS Offset Error Correction Value
34.3.9 ADC Plus-Side Gain Register (ADCx_PG)
The Plus-Side Gain Register (PG) contains the gain error correction for the plus-side
input in differential mode or the overall conversion in single-ended mode. PG, a 16-bit
real number in binary format, is the gain adjustment factor, with the radix point fixed
between PG[15] and PG[14]. This register must be written by the user with the value
described in the calibration procedure. Otherwise, the gain error specifications may not
be met.
For more information regarding the calibration procedure, please refer to the Calibration
function section.
Address:
Base address + 2Ch offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
PG
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
ADCx_PG field descriptions
Field Description
31–16
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
PG Plus-Side Gain
34.3.10 ADC Minus-Side Gain Register (ADCx_MG)
The Minus-Side Gain Register (MG) contains the gain error correction for the minus-side
input in differential mode. This register is ignored in single-ended mode. MG, a 16-bit
real number in binary format, is the gain adjustment factor, with the radix point fixed
between MG[15] and MG[14]. This register must be written by the user with the value
described in the calibration procedure. Otherwise, the gain error specifications may not
be met.
For more information regarding the calibration procedure, please refer to the Calibration
function section.
Chapter 34 Analog-to-Digital Converter (ADC)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 781
