FTMx_PWMLOAD field descriptions (continued)
Field Description
4
CH4SEL
Channel 4 Select
0 Do not include the channel in the matching process.
1 Include the channel in the matching process.
3
CH3SEL
Channel 3 Select
0 Do not include the channel in the matching process.
1 Include the channel in the matching process.
2
CH2SEL
Channel 2 Select
0 Do not include the channel in the matching process.
1 Include the channel in the matching process.
1
CH1SEL
Channel 1 Select
0 Do not include the channel in the matching process.
1 Include the channel in the matching process.
0
CH0SEL
Channel 0 Select
0 Do not include the channel in the matching process.
1 Include the channel in the matching process.
39.4 Functional description
The notation used in this document to represent the counters and the generation of the
signals is shown in the following figure.
Functional description
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
946 NXP Semiconductors
