FTMx_OUTINIT field descriptions (continued)
Field Description
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
5
CH5OI
Channel 5 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
4
CH4OI
Channel 4 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
3
CH3OI
Channel 3 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
2
CH2OI
Channel 2 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
1
CH1OI
Channel 1 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
0
CH0OI
Channel 0 Output Initialization Value
Selects the value that is forced into the channel output when the initialization occurs.
0 The initialization value is 0.
1 The initialization value is 1.
39.3.13 Output Mask (FTMx_OUTMASK)
This register provides a mask for each FTM channel. The mask of a channel determines if
its output responds, that is, it is masked or not, when a match occurs. This feature is used
for BLDC control where the PWM signal is presented to an electric motor at specific
times to provide electronic commutation.
Chapter 39 FlexTimer Module (FTM)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 917
