Process command
Host
Target
Reset
0x5a a4 04 00 6f 46 0b 00 00 00
GenericResponse:
0x5a a4 0c 00 f8 0b a
0 00 04 02 00 00 00 00 0b 00 00 00
ACK :
0x5a a1
ACK:
0x5a a1
Figure 13-17. Protocol Sequence for Reset Command
Table 13-42. Reset Command Packet Format (Example)
Reset Parameter Value
Framing packet start byte 0x5A
packetType 0xA4, kFramingPacketType_Command
length 0x04 0x00
crc16 0x6F 0x46
Command packet commandTag 0x0B - reset
flags 0x00
reserved 0x00
parameterCount 0x00
The Reset command has no data phase.
Response: The target (Kinetis Flashloader) will return a GenericResponse packet with
status code set to kStatus_Success, before resetting the chip.
