SMC_PMSTAT field descriptions (continued)

Field Description

NOTE:

When a PSTOP mode is enabled, the PMSTAT will not update to STOP or VLPS

0000_0001 Current power mode is RUN.

0000_0010 Current power mode is STOP.

0000_0100 Current power mode is VLPR.

0000_1000 Current power mode is VLPW.

0001_0000 Current power mode is VLPS.

0010_0000 Current power mode is LLS.

0100_0000 Current power mode is VLLS.

1000_0000 Current power mode is HSRUN

15.4 Functional description

15.4.1 Power mode transitions

The following figure shows the power mode state transitions available on the chip. Any

reset always brings the MCU back to the normal RUN state.
