LLWU_F2 field descriptions (continued)
Field Description
4
WUF12
Wakeup Flag For LLWU_P12
Indicates that an enabled external wakeup pin was a source of exiting a low-leakage power mode. To
clear the flag, write a 1 to WUF12.
0 LLWU_P12 input was not a wakeup source
1 LLWU_P12 input was a wakeup source
3
WUF11
Wakeup Flag For LLWU_P11
Indicates that an enabled external wakeup pin was a source of exiting a low-leakage power mode. To
clear the flag, write a 1 to WUF11.
0 LLWU_P11 input was not a wakeup source
1 LLWU_P11 input was a wakeup source
2
WUF10
Wakeup Flag For LLWU_P10
Indicates that an enabled external wakeup pin was a source of exiting a low-leakage power mode. To
clear the flag, write a 1 to WUF10.
0 LLWU_P10 input was not a wakeup source
1 LLWU_P10 input was a wakeup source
1
WUF9
Wakeup Flag For LLWU_P9
Indicates that an enabled external wakeup pin was a source of exiting a low-leakage power mode. To
clear the flag, write a 1 to WUF9.
0 LLWU_P9 input was not a wakeup source
1 LLWU_P9 input was a wakeup source
0
WUF8
Wakeup Flag For LLWU_P8
Indicates that an enabled external wakeup pin was a source of exiting a low-leakage power mode. To
clear the flag, write a 1 to WUF8.
0 LLWU_P8 input was not a wakeup source
1 LLWU_P8 input was a wakeup source
17.3.8 LLWU Flag 3 register (LLWU_F3)
LLWU_F3 contains the wakeup flags indicating which internal wakeup source caused the
MCU to exit LLS or VLLS mode. For LLS, this is the source causing the CPU interrupt
flow. For VLLS, this is the source causing the MCU reset flow.
For internal peripherals that are capable of running in a low-leakage power mode, such as
a real time clock module or CMP module, the flag from the associated peripheral is
accessible as the MWUFx bit. The flag will need to be cleared in the peripheral instead of
writing a 1 to the MWUFx bit.
