SIM_SOPT8 field descriptions (continued)
Field Description
0 No effect.
1 Write 1 to assert the TRIG0 input to FTM2, software must clear this bit to allow other trigger sources
to assert.
1
FTM1SYNCBIT
FTM1 Hardware Trigger 0 Software Synchronization
0 No effect.
1 Write 1 to assert the TRIG0 input to FTM1, software must clear this bit to allow other trigger sources
to assert.
0
FTM0SYNCBIT
FTM0 Hardware Trigger 0 Software Synchronization
0 No effect
1 Write 1 to assert the TRIG0 input to FTM0, software must clear this bit to allow other trigger sources
to assert.
12.2.8 System Device Identification Register (SIM_SDID)
Address: 4004_7000h base + 1024h offset = 4004_8024h
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
FAMILYID SUBFAMID SERIESID 0 REVID DIEID FAMID PINID
W
Reset
x* x* x* x* x* x* x* x* x* x* x* x* 0 0 0 0 x* x* x* x* 1 1 1 0 1 x* x* x* x* x* x* x*
* Notes:
x = Undefined at reset.•
SIM_SDID field descriptions
Field Description
31–28
FAMILYID
Kinetis Family ID
Specifies the Kinetis family of the device.
0000 K0x Family
0001 K1x Family
0010 K2x Family
0011 K3x Family
0100 K4x Family
0110 K6x Family
0111 K7x Family
1000 K8x Family
27–24
SUBFAMID
Kinetis Sub-Family ID
Specifies the Kinetis sub-family of the device.
0000 Kx0 Subfamily
0001 Kx1 Subfamily (tamper detect)
Table continues on the next page...
Chapter 12 System Integration Module (SIM)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 275
