Address: Base address + 30h offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
MG
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
ADCx_MG field descriptions
Field Description
31–16
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
MG Minus-Side Gain
34.3.11 ADC Plus-Side General Calibration Value Register
(ADCx_CLPD)
The Plus-Side General Calibration Value Registers (CLPx) contain calibration
information that is generated by the calibration function. These registers contain seven
calibration values of varying widths: CLP0[5:0], CLP1[6:0], CLP2[7:0], CLP3[8:0],
CLP4[9:0], CLPS[5:0], and CLPD[5:0]. CLPx are automatically set when the self-
calibration sequence is done, that is, CAL is cleared. If these registers are written by the
user after calibration, the linearity error specifications may not be met.
For more information regarding the calibration procedure, please refer to the Calibration
function section.
Address:
Base address + 34h offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CLPD
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 0
ADCx_CLPD field descriptions
Field Description
31–6
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
CLPD Calibration Value
Calibration Value
Memory map and register definitions
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
782 NXP Semiconductors
