Address: Base address + C8h offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
FILT
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PORTx_DFWR field descriptions
Field Description
31–5
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
FILT Filter Length
The digital filter configuration is valid in all digital pin muxing modes. Configures the maximum size of the
glitches, in clock cycles, that the digital filter absorbs for the enabled digital filters. Glitches that are longer
than this register setting will pass through the digital filter, and glitches that are equal to or less than this
register setting are filtered. Changing the filter length must be done only after all filters are disabled.
11.6 Functional description
11.6.1 Pin control
Each port pin has a corresponding Pin Control register, PORT_PCRn, associated with it.
The upper half of the Pin Control register configures the pin's capability to either
interrupt the CPU or request a DMA transfer, on a rising/falling edge or both edges as
well as a logic level occurring on the port pin. It also includes a flag to indicate that an
interrupt has occurred.
The lower half of the Pin Control register configures the following functions for each pin
within the 32-bit port.
• Pullup or pulldown enable
• Drive strength and slew rate configuration
• Open drain enable
• Passive input filter enable
• Pin Muxing mode
The functions apply across all digital pin muxing modes and individual peripherals do not
override the configuration in the Pin Control register. For example, if an I
2
C function is
enabled on a pin, that does not override the pullup or open drain configuration for that
pin.
Functional description
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
254 NXP Semiconductors
