34.3.14 ADC Plus-Side General Calibration Value Register
(ADCx_CLP3)
For more information, see CLPD register description.
Address: Base address + 40h offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CLP3
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
ADCx_CLP3 field descriptions
Field Description
31–9
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
CLP3 Calibration Value
Calibration Value
34.3.15 ADC Plus-Side General Calibration Value Register
(ADCx_CLP2)
For more information, see CLPD register description.
Address:
Base address + 44h offset
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CLP2
W
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
ADCx_CLP2 field descriptions
Field Description
31–8
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
CLP2 Calibration Value
Calibration Value
Memory map and register definitions
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
784 NXP Semiconductors
