3.4.2 OSC Configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
Signal
multiplexing
Register
access
Peripheral
bridge
System
oscillator
MCG
Module signals
Figure 3-17. OSC configuration
Table 3-29. Reference links to related information
Topic Related module Reference
Full description OSC OSC
System memory map System memory map
Clocking Clock distribution
Power management Power management
Signal multiplexing Port control Signal multiplexing
Full description MCG MCG
3.4.2.1 OSC modes of operation with MCG
The MCG's C2 register bits configure the oscillator frequency range. See the OSC and
MCG chapters for more details.
3.4.3
RTC OSC configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
Chapter 3 Chip Configuration
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 83
