Table 3-25. WDOG clock connections (continued)
Module clock Chip clock
Alt Clock Bus Clock
Fast Test Clock Bus Clock
System Bus Clock Bus Clock
3.3.11.2 WDOG low-power modes
This table shows the WDOG low-power modes and the corresponding chip low-power
modes.
Table 3-26. WDOG low-power modes
Module mode Chip mode
Wait Wait, VLPW
Stop Stop, VLPS
Power Down LLS, VLLSx
3.4 Clock modules
3.4.1 MCG Configuration
This section summarizes how the module has been configured in the chip. For a
comprehensive description of the module itself, see the module’s dedicated chapter.
