SIM_UIDMH field descriptions
Field Description
UID Unique Identification
Unique identification for the device.
12.2.19 Unique Identification Register Mid Low (SIM_UIDML)
Address: 4004_7000h base + 105Ch offset = 4004_805Ch
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
UID
W
Reset
0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0*
SIM_UIDML field descriptions
Field Description
UID Unique Identification
Unique identification for the device.
12.2.20 Unique Identification Register Low (SIM_UIDL)
Address: 4004_7000h base + 1060h offset = 4004_8060h
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
UID
W
Reset
0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0* 0*
SIM_UIDL field descriptions
Field Description
UID Unique Identification
Unique identification for the device.
12.3 Functional description
For more information about the functions of SIM, see the Introduction section.
Chapter 12 System Integration Module (SIM)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 291
