EXTAL32

XTAL32

DAC0_OUT/CMP1_IN3/ADC0_SE23

VREF_OUT/CMP1_IN5/CMP0_IN5/ADC1_SE18

VSSA

VREFL

VREFH

VDDA

ADC1_DM0/ADC0_DM3

ADC1_DP0/ADC0_DP3

ADC0_DM0/ADC1_DM3

ADC0_DP0/ADC1_DP3

VREGIN

VOUT33

USB0_DM

USB0_DP

VSS

VDD

PTE1/LLWU_P0

PTE0/CLKOUT32K

PTD7

PTD6/LLWU_P15

PTD5

PTD4/LLWU_P14

PTD3

PTD2/LLWU_P13

PTD1

PTD0/LLWU_P12

PTC11/LLWU_P11

PTC10

PTC9

PTC8

PTC7

PTC6/LLWU_P10

PTC5/LLWU_P9

PTC4/LLWU_P8

VDD

VSS

PTC3/LLWU_P7

PTC2

PTC1/LLWU_P6

PTC0

PTB19

PTB18

PTB17

PTB16

PTB3

PTB2

PTB1

PTB0/LLWU_P5

RESET_b

PTA19

PTA18

VSS

VDD

PTA13/LLWU_P4

PTA12

PTA5

PTA4/LLWU_P3

PTA3

PTA2

PTA1

PTA0

VBAT

Figure 10-2. K22F 64 LQFP pinout diagram (top view)

Chapter 10 Signal Multiplexing and Signal Descriptions

K22F Sub-Family Reference Manual, Rev. 4, 08/2016

NXP Semiconductors 223

Default Chapter3
