NXP Semiconductors K22F series - Page 521

0xC520
0xD928
Fast
Fn Test
Clock
Allow update for N bus
clk cycles
N bus clk cycles
LPO
N bus clk cycles
Refresh Sequence
2 writes of data within K
bus clock cycles of each
other
Unlock Sequence
2 Writes of data within K bus clock
cycles of each other
Disable Control/Configuration
bit changes N bus clk cycles after
unlocking
WDOGEN = WDOG Enable
WINEN = Windowed Mode Enable
WDOGT = WDOG Time-out Value
WDOGCLKSRC = WDOG Clock Source
WDOG Test = WDOG Test Mode
WAIT EN = Enable in wait mode
STOP EN = Enable in stop mode
Debug EN = Enable in debug mode
SRS = System Reset Status Register
R = Timer Reload
WDOG
reset count
Alt Clock
Osc
WDOG
Clock
Selection
WDOG CLK
R
System reset
and SRS register
Interrupt
IRQ_RST_
EN = = 1?
Invalid
Unlock Seq
32-bit Timer
Timer Time-out
Refresh
Outside
Window
Invalid Refresh
Seq
No config
after unlocking
No unlock
after reset
0xB480
0xA602
System
Bus Clock
32-bit Modulus Reg
(Time-out Value)
DebugEN
Window_begin
WDOGTEST
STOPEN
WAITEN
WDOGT
WDOG
CLKSRC
WINEN
WDOGEN
WDOG
Y
N
Figure 24-1. WDOG operation
The preceding figure shows the operation of the watchdog. The values for N and K are:
• N = 256
• K = 20
The watchdog is a fail safe mechanism that brings the system into a known initial state in
case of its failure due to CPU clock stopping or a run-away condition in code execution.
In its simplest form, the watchdog timer runs continuously off a clock source and expects
to be serviced periodically, failing which it resets the system. This ensures that the
software is executing correctly and has not run away in an unintended direction. Software
can adjust the period of servicing or the time-out value for the watchdog timer to meet the
needs of the application.
