ADC memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4002_7014 ADC Data Result Register (ADC1_RB) 32 R 0000_0000h 34.3.4/774
4002_7018 Compare Value Registers (ADC1_CV1) 32 R/W 0000_0000h 34.3.5/776
4002_701C Compare Value Registers (ADC1_CV2) 32 R/W 0000_0000h 34.3.5/776
4002_7020 Status and Control Register 2 (ADC1_SC2) 32 R/W 0000_0000h 34.3.6/777
4002_7024 Status and Control Register 3 (ADC1_SC3) 32 R/W 0000_0000h 34.3.7/779
4002_7028 ADC Offset Correction Register (ADC1_OFS) 32 R/W 0000_0004h 34.3.8/780
4002_702C ADC Plus-Side Gain Register (ADC1_PG) 32 R/W 0000_8200h 34.3.9/781
4002_7030 ADC Minus-Side Gain Register (ADC1_MG) 32 R/W 0000_8200h
34.3.10/
781
4002_7034
ADC Plus-Side General Calibration Value Register
(ADC1_CLPD)
32 R/W 0000_000Ah
34.3.11/
782
4002_7038
ADC Plus-Side General Calibration Value Register
(ADC1_CLPS)
32 R/W 0000_0020h
34.3.12/
783
4002_703C
ADC Plus-Side General Calibration Value Register
(ADC1_CLP4)
32 R/W 0000_0200h
34.3.13/
783
4002_7040
ADC Plus-Side General Calibration Value Register
(ADC1_CLP3)
32 R/W 0000_0100h
34.3.14/
784
4002_7044
ADC Plus-Side General Calibration Value Register
(ADC1_CLP2)
32 R/W 0000_0080h
34.3.15/
784
4002_7048
ADC Plus-Side General Calibration Value Register
(ADC1_CLP1)
32 R/W 0000_0040h
34.3.16/
785
4002_704C
ADC Plus-Side General Calibration Value Register
(ADC1_CLP0)
32 R/W 0000_0020h
34.3.17/
785
4002_7054
ADC Minus-Side General Calibration Value Register
(ADC1_CLMD)
32 R/W 0000_000Ah
34.3.18/
786
4002_7058
ADC Minus-Side General Calibration Value Register
(ADC1_CLMS)
32 R/W 0000_0020h
34.3.19/
786
4002_705C
ADC Minus-Side General Calibration Value Register
(ADC1_CLM4)
32 R/W 0000_0200h
34.3.20/
787
4002_7060
ADC Minus-Side General Calibration Value Register
(ADC1_CLM3)
32 R/W 0000_0100h
34.3.21/
787
4002_7064
ADC Minus-Side General Calibration Value Register
(ADC1_CLM2)
32 R/W 0000_0080h
34.3.22/
788
4002_7068
ADC Minus-Side General Calibration Value Register
(ADC1_CLM1)
32 R/W 0000_0040h
34.3.23/
788
4002_706C
ADC Minus-Side General Calibration Value Register
(ADC1_CLM0)
32 R/W 0000_0020h
34.3.24/
789
4003_B000 ADC Status and Control Registers 1 (ADC0_SC1A) 32 R/W 0000_001Fh 34.3.1/768
4003_B004 ADC Status and Control Registers 1 (ADC0_SC1B) 32 R/W 0000_001Fh 34.3.1/768
4003_B008 ADC Configuration Register 1 (ADC0_CFG1) 32 R/W 0000_0000h 34.3.2/772
4003_B00C ADC Configuration Register 2 (ADC0_CFG2) 32 R/W 0000_0000h 34.3.3/773
4003_B010 ADC Data Result Register (ADC0_RA) 32 R 0000_0000h 34.3.4/774
Table continues on the next page...
Chapter 34 Analog-to-Digital Converter (ADC)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 767
