DAC memory map
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4002_8000 DAC Data Low Register (DAC1_DAT0L) 8 R/W 00h 36.4.1/849
4002_8001 DAC Data High Register (DAC1_DAT0H) 8 R/W 00h 36.4.2/849
4002_8002 DAC Data Low Register (DAC1_DAT1L) 8 R/W 00h 36.4.1/849
4002_8003 DAC Data High Register (DAC1_DAT1H) 8 R/W 00h 36.4.2/849
4002_8004 DAC Data Low Register (DAC1_DAT2L) 8 R/W 00h 36.4.1/849
4002_8005 DAC Data High Register (DAC1_DAT2H) 8 R/W 00h 36.4.2/849
4002_8006 DAC Data Low Register (DAC1_DAT3L) 8 R/W 00h 36.4.1/849
4002_8007 DAC Data High Register (DAC1_DAT3H) 8 R/W 00h 36.4.2/849
4002_8008 DAC Data Low Register (DAC1_DAT4L) 8 R/W 00h 36.4.1/849
4002_8009 DAC Data High Register (DAC1_DAT4H) 8 R/W 00h 36.4.2/849
4002_800A DAC Data Low Register (DAC1_DAT5L) 8 R/W 00h 36.4.1/849
4002_800B DAC Data High Register (DAC1_DAT5H) 8 R/W 00h 36.4.2/849
4002_800C DAC Data Low Register (DAC1_DAT6L) 8 R/W 00h 36.4.1/849
4002_800D DAC Data High Register (DAC1_DAT6H) 8 R/W 00h 36.4.2/849
4002_800E DAC Data Low Register (DAC1_DAT7L) 8 R/W 00h 36.4.1/849
4002_800F DAC Data High Register (DAC1_DAT7H) 8 R/W 00h 36.4.2/849
4002_8010 DAC Data Low Register (DAC1_DAT8L) 8 R/W 00h 36.4.1/849
4002_8011 DAC Data High Register (DAC1_DAT8H) 8 R/W 00h 36.4.2/849
4002_8012 DAC Data Low Register (DAC1_DAT9L) 8 R/W 00h 36.4.1/849
4002_8013 DAC Data High Register (DAC1_DAT9H) 8 R/W 00h 36.4.2/849
4002_8014 DAC Data Low Register (DAC1_DAT10L) 8 R/W 00h 36.4.1/849
4002_8015 DAC Data High Register (DAC1_DAT10H) 8 R/W 00h 36.4.2/849
4002_8016 DAC Data Low Register (DAC1_DAT11L) 8 R/W 00h 36.4.1/849
4002_8017 DAC Data High Register (DAC1_DAT11H) 8 R/W 00h 36.4.2/849
4002_8018 DAC Data Low Register (DAC1_DAT12L) 8 R/W 00h 36.4.1/849
4002_8019 DAC Data High Register (DAC1_DAT12H) 8 R/W 00h 36.4.2/849
4002_801A DAC Data Low Register (DAC1_DAT13L) 8 R/W 00h 36.4.1/849
4002_801B DAC Data High Register (DAC1_DAT13H) 8 R/W 00h 36.4.2/849
4002_801C DAC Data Low Register (DAC1_DAT14L) 8 R/W 00h 36.4.1/849
4002_801D DAC Data High Register (DAC1_DAT14H) 8 R/W 00h 36.4.2/849
4002_801E DAC Data Low Register (DAC1_DAT15L) 8 R/W 00h 36.4.1/849
4002_801F DAC Data High Register (DAC1_DAT15H) 8 R/W 00h 36.4.2/849
4002_8020 DAC Status Register (DAC1_SR) 8 R/W 02h 36.4.3/850
4002_8021 DAC Control Register (DAC1_C0) 8 R/W 00h 36.4.4/851
4002_8022 DAC Control Register 1 (DAC1_C1) 8 R/W 00h 36.4.5/852
4002_8023 DAC Control Register 2 (DAC1_C2) 8 R/W 0Fh 36.4.6/853
4003_F000 DAC Data Low Register (DAC0_DAT0L) 8 R/W 00h 36.4.1/849
4003_F001 DAC Data High Register (DAC0_DAT0H) 8 R/W 00h 36.4.2/849
Table continues on the next page...
Chapter 36 12-bit Digital-to-Analog Converter (DAC)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 847
