FTMx_COMBINE field descriptions
Field Description
31
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
30
FAULTEN3
Fault Control Enable For n = 6
Enables the fault control in channels (n) and (n+1).
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The fault control in this pair of channels is disabled.
1 The fault control in this pair of channels is enabled.
29
SYNCEN3
Synchronization Enable For n = 6
Enables PWM synchronization of registers C(n)V and C(n+1)V.
0 The PWM synchronization in this pair of channels is disabled.
1 The PWM synchronization in this pair of channels is enabled.
28
DTEN3
Deadtime Enable For n = 6
Enables the deadtime insertion in the channels (n) and (n+1).
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The deadtime insertion in this pair of channels is disabled.
1 The deadtime insertion in this pair of channels is enabled.
27
DECAP3
Dual Edge Capture Mode Captures For n = 6
Enables the capture of the FTM counter value according to the channel (n) input event and the
configuration of the dual edge capture bits.
This field applies only when DECAPEN = 1.
DECAP bit is cleared automatically by hardware if dual edge capture – one-shot mode is selected and
when the capture of channel (n+1) event is made.
0 The dual edge captures are inactive.
1 The dual edge captures are active.
26
DECAPEN3
Dual Edge Capture Mode Enable For n = 6
Enables the Dual Edge Capture mode in the channels (n) and (n+1). This bit reconfigures the function of
MSnA, ELSnB:ELSnA and ELS(n+1)B:ELS(n+1)A bits in Dual Edge Capture mode according to Table
39-2.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The Dual Edge Capture mode in this pair of channels is disabled.
1 The Dual Edge Capture mode in this pair of channels is enabled.
25
COMP3
Complement Of Channel (n) for n = 6
Enables Complementary mode for the combined channels. In Complementary mode the channel (n+1)
output is the inverse of the channel (n) output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel (n+1) output is the same as the channel (n) output.
1 The channel (n+1) output is the complement of the channel (n) output.
Table continues on the next page...
Memory map and register definition
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
920 NXP Semiconductors
