FTMx_POL field descriptions
Field Description
31–8
Reserved
This field is reserved.
7
POL7
Channel 7 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
6
POL6
Channel 6 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
5
POL5
Channel 5 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
4
POL4
Channel 4 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
3
POL3
Channel 3 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
2
POL2
Channel 2 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
0 The channel polarity is active high.
1 The channel polarity is active low.
1
POL1
Channel 1 Polarity
Defines the polarity of the channel output.
This field is write protected. It can be written only when MODE[WPDIS] = 1.
Table continues on the next page...
