FTMx_SYNCONF field descriptions (continued)
Field Description
20
HWSOC
Software output control synchronization is activated by a hardware trigger.
0 A hardware trigger does not activate the SWOCTRL register synchronization.
1 A hardware trigger activates the SWOCTRL register synchronization.
19
HWINVC
Inverting control synchronization is activated by a hardware trigger.
0 A hardware trigger does not activate the INVCTRL register synchronization.
1 A hardware trigger activates the INVCTRL register synchronization.
18
HWOM
Output mask synchronization is activated by a hardware trigger.
0 A hardware trigger does not activate the OUTMASK register synchronization.
1 A hardware trigger activates the OUTMASK register synchronization.
17
HWWRBUF
MOD, CNTIN, and CV registers synchronization is activated by a hardware trigger.
0 A hardware trigger does not activate MOD, CNTIN, and CV registers synchronization.
1 A hardware trigger activates MOD, CNTIN, and CV registers synchronization.
16
HWRSTCNT
FTM counter synchronization is activated by a hardware trigger.
0 A hardware trigger does not activate the FTM counter synchronization.
1 A hardware trigger activates the FTM counter synchronization.
15–13
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
12
SWSOC
Software output control synchronization is activated by the software trigger.
0 The software trigger does not activate the SWOCTRL register synchronization.
1 The software trigger activates the SWOCTRL register synchronization.
11
SWINVC
Inverting control synchronization is activated by the software trigger.
0 The software trigger does not activate the INVCTRL register synchronization.
1 The software trigger activates the INVCTRL register synchronization.
10
SWOM
Output mask synchronization is activated by the software trigger.
0 The software trigger does not activate the OUTMASK register synchronization.
1 The software trigger activates the OUTMASK register synchronization.
9
SWWRBUF
MOD, CNTIN, and CV registers synchronization is activated by the software trigger.
0 The software trigger does not activate MOD, CNTIN, and CV registers synchronization.
1 The software trigger activates MOD, CNTIN, and CV registers synchronization.
8
SWRSTCNT
FTM counter synchronization is activated by the software trigger.
0 The software trigger does not activate the FTM counter synchronization.
1 The software trigger activates the FTM counter synchronization.
7
SYNCMODE
Synchronization Mode
Selects the PWM Synchronization mode.
0 Legacy PWM synchronization is selected.
1 Enhanced PWM synchronization is selected.
Table continues on the next page...
Memory map and register definition
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
