Chapter 2: LPC176x/5x Memory map
Figure 3 and Table 4 show different views of the peripheral address space. The AHB
peripheral area is 2 megabyte in size, and is divided to allow for up to 128 peripherals.
The APB peripheral area is 1 megabyte in size and is divided to allow for up to 64
peripherals. Each peripheral of either type is allocated 16 kilobytes of space. This allows
simplifying the address decoding for each peripheral.
All peripheral register addresses are word aligned (to 32-bit boundaries) regardless of
their size. This eliminates the need for byte lane mapping hardware that would be required
to allow byte (8-bit) or half-word (16-bit) accesses to occur at smaller boundaries. An
implication of this is that word and half-word registers must be accessed all at once. For
example, it is not possible to read or write the upper byte of a word register separately.
2.3 APB peripheral addresses
The following table shows the APB0/1 address maps. No APB peripheral uses all of the
16 kB space allocated to it. Typically each device’s registers are "aliased" or repeated at
multiple locations within each 16 kB range.
Table 4. APB0 peripherals and base addresses
APB0 peripheral Base address Peripheral name
0 0x4000 0000 Watchdog Timer
1 0x4000 4000 Timer 0
2 0x4000 8000 Timer 1
3 0x4000 C000 UART0
4 0x4001 0000 UART1
5 0x4001 4000 reserved
6 0x4001 8000 PWM1
7 0x4001 C000 I
2
C0
8 0x4002 0000 SPI
9 0x4002 4000 RTC
10 0x4002 8000 GPIO interrupts
11 0x4002 C000 Pin Connect Block
12 0x4003 0000 SSP1
13 0x4003 4000 ADC
14 0x4003 8000 CAN Acceptance Filter RAM
15 0x4003 C000 CAN Acceptance Filter Registers
16 0x4004 0000 CAN Common Registers
17 0x4004 4000 CAN Controller 1
18 0x4004 8000 CAN Controller 2
19 to 22 0x4004 C000 to 0x4005 8000 reserved
23 0x4005 C000 I
2
C1
24 to 31 0x4006 0000 to 0x4007 C000 reserved
