Chapter 34: Appendix: Cortex-M3 user guide
• Section 34.2.3.1 “Operands”
• Section 34.2.3.2 “Restrictions when using PC or SP”
• Section 34.2.3.3 “Flexible second operand”
• Section 34.2.3.4 “Shift Operations”
• Section 34.2.3.5 “Address alignment”
• Section 34.2.3.6 “PC-relative expressions”
• Section 34.2.3.7 “Conditional execution”
• Section 34.2.3.8 “Instruction width selection”.
34.2.3.1 Operands
An instruction operand can be an ARM register, a constant, or another instruction-specific
parameter. Instructions act on the operands and often store the result in a destination
register. When there is a destination register in the instruction, it is usually specified before
the operands.
Operands in some instructions are flexible in that they can either be a register or a
constant. See Section 34.2.3.3
.
34.2.3.2 Restrictions when using PC or SP
Many instructions have restrictions on whether you can use the Program Counter (PC)
or Stack Pointer (SP) for the operands or destination register. See instruction
descriptions for more information.
Remark: Bit[0] of any address you write to the PC with a
BX , BLX , LDM , LDR , or POP instruction
must be 1 for correct execution, because this bit indicates the required instruction set, and
the Cortex-M3 processor only supports Thumb instructions.
34.2.3.3 Flexible second operand
Many general data processing instructions have a flexible second operand. This is shown
as Operand2 in the descriptions of the syntax of each instruction.
Operand2 can be a:
• Section 34.2.3.3.1 “Constant”
• Section 34.2.3.3.2 “Register with optional shift”
34.2.3.3.1 Constant
You specify an Operand2 constant in the form:
#
constant
where constant can be:
• any constant that can be produced by shifting an 8-bit value left by any number of bits
within a 32-bit word
• any constant of the form 0x00XY00XY
• any constant of the form 0xXY00XY00
• any constant of the form 0xXYXYXYXY .
