UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 20 December 2013 797 of 841
NXP Semiconductors
UM10360
Chapter 34: Appendix: Cortex-M3 user guide
34.4.5.9 MPU design hints and tips
To avoid unexpected behavior, disable the interrupts before updating the attributes of a
region that the interrupt handlers might access.
Ensure software uses aligned accesses of the correct size to access MPU registers:
• except for the RASR, it must use aligned word accesses
• for the RASR it can use byte or aligned halfword or word accesses.
The processor does not support unaligned accesses to MPU registers.
When setting up the MPU, and if the MPU has previously been programmed, disable
unused regions to prevent any previous region settings from affecting the new MPU
setup.
34.4.5.9.1 MPU configuration for a microcontroller
Usually, a microcontroller system has only a single processor and no caches. In such a
system, program the MPU as follows:
In most microcontroller implementations, the shareability and cache policy attributes do
not affect the system behavior. However, using these settings for the MPU regions can
make the application code more portable. The values given are for typical situations. In
special systems, such as multiprocessor designs or designs with a separate DMA engine,
the shareability attribute might be important. In these cases refer to the recommendations
of the memory device manufacturer.
Fig 150. SRD example
5HJLRQ
'LVDEOHGVXEUHJLRQ
'LVDEOHGVXEUHJLRQ
5HJLRQZLWK
VXEUHJLRQV
%DVHDGGUHVVRIERWKUHJLRQV
2IIVHWIURP
EDVHDGGUHVV
.%
.%
.%
.%
.%
.%
.%
.%
Table 690. Memory region attributes for a microcontroller
Memory region TEX C B S Memory type and attributes
Flash memory b000 1 0 0 Normal memory, Non-shareable, write-through
Internal SRAM b000 1 0 1 Normal memory, Shareable, write-through
External SRAM b000 1 1 1 Normal memory, Shareable, write-back,
write-allocate
Peripherals b000 0 1 1 Device memory, Shareable
