NXP Semiconductors LPC1768 - QEI Interrupt Clear Register (QEICLR - 0 X400 B CFE8); QEI Interrupt Enable Register (QEIIE - 0 X400 B CFE4)

UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 556 of 841
NXP Semiconductors
UM10360
Chapter 26: LPC176x/5x Quadrature Encoder Interface (QEI)
26.6.4.3 QEI Interrupt Clear register (QEICLR - 0x400B CFE8)
Writing a 1 to a bit in this register clears the corresponding bit in the QEI Interrupt Status
register (QEISTAT).
26.6.4.4 QEI Interrupt Enable register (QEIIE - 0x400B CFE4)
This register enables interrupt sources. Bits set to 1 enable the corresponding interrupt; a
0 bit disables the corresponding interrupt.
10 POS0REV_Int Combined position 0 and revolution count interrupt. Set when both the POS0_Int bit is set
and the REV_Int is set.
0
11 POS1REV_Int Combined position 1 and revolution count interrupt. Set when both the POS1_Int bit is set
and the REV_Int is set.
0
12 POS2REV_Int Combined position 2 and revolution count interrupt. Set when both the POS2_Int bit is set
and the REV_Int is set.
0
31:13 - reserved 0
Table 501: QEI Interrupt Set register (QEISET - address 0x400B CFEC) bit description …continued
Bit Symbol Description Reset
value
Table 502: QEI Interrupt Clear register (QEICLR - 0x400B CFE8) bit description
Bit Symbol Description Reset
value
0 INX_Int Indicates that an index pulse was detected. 0
1 TIM_Int Indicates that a velocity timer overflow occurred 0
2 VELC_Int Indicates that captured velocity is less than compare velocity. 0
3 DIR_Int Indicates that a change of direction was detected. 0
4 ERR_Int Indicates that an encoder phase error was detected. 0
5 ENCLK_Int Indicates that and encoder clock pulse was detected.
6 POS0_Int Indicates that the position 0 compare value is equal to the current position. 0
7 POS1_Int Indicates that the position 1compare value is equal to the current position. 0
8 POS2_Int Indicates that the position 2 compare value is equal to the current position. 0
9 REV_Int Indicates that the index compare value is equal to the current index count. 0
10 POS0REV_Int Combined position 0 and revolution count interrupt. Set when both the POS0_Int bit is set
and the REV_Int is set.
0
11 POS1REV_Int Combined position 1 and revolution count interrupt. Set when both the POS1_Int bit is set
and the REV_Int is set.
0
12 POS2REV_Int Combined position 2 and revolution count interrupt. Set when both the POS2_Int bit is set
and the REV_Int is set.
0
31:13 - reserved 0
Table 503: QEI Interrupt Enable register (QEIIE - address 0x400B CFE4) bit description
Bit Symbol Description Reset
value
0 INX_Int Indicates that an index pulse was detected. 0
1 TIM_Int Indicates that a velocity timer overflow occurred 0
2 VELC_Int Indicates that captured velocity is less than compare velocity. 0
3 DIR_Int Indicates that a change of direction was detected. 0
