Chapter 34: Appendix: Cortex-M3 user guide
34.2.5.3.4 Condition flags
If S is specified:
• these instructions update the N and Z flags according to the result
• the C flag is updated to the last bit shifted out, except when the shift length is 0, see
Section 34.2.3.4 “
Shift Operations”.
34.2.5.3.5 Examples
ASR R7, R8, #9 ; Arithmetic shift right by 9 bits
LSLS R1, R2, #3 ; Logical shift left by 3 bits with flag update
LSR R4, R5, #6 ; Logical shift right by 6 bits
ROR R4, R5, R6 ; Rotate right by the value in the bottom byte of R6
RRX R4, R5 ; Rotate right with extend
