Page #121 background imageLoading...
Page #121 background image
UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 121 of 841
9.1 Basic configuration
GPIOs are configured using the following registers:
1. Power: always enabled.
2. Pins: See Section 8.3
for GPIO pins and their modes.
3. Wake-up: GPIO ports 0 and 2 can be used for wake-up if needed, see (Section 4.8.8
).
4. Interrupts: Enable GPIO interrupts in IO0/2IntEnR (Table 114
) or IO0/2IntEnF
(Table 116
). Interrupts are enabled in the NVIC using the appropriate Interrupt Set
Enable register.
9.2 Features
9.2.1 Digital I/O ports
• Accelerated GPIO functions:
– GPIO registers are located on a peripheral AHB bus for fast I/O timing.
– Mask registers allow treating sets of port bits as a group, leaving other bits
unchanged.
– All GPIO registers are byte, half-word, and word addressable.
– Entire port value can be written in one instruction.
– GPIO registers are accessible by the GPDMA.
• Bit-level set and clear registers allow a single instruction set or clear of any number of
bits in one port.
• All GPIO registers support Cortex-M3 bit-banding.
• GPIO registers are accessible by the GPDMA controller to allow DMA of data to or
from GPIOs, synchronized to any DMA request.
• Direction control of individual port bits.
• All I/Os default to input with pullup after reset.
9.2.2 Interrupt generating digital ports
• Port 0 and Port 2 can provide a single interrupt for any combination of port pins.
• Each port pin can be programmed to generate an interrupt on a rising edge, a falling
edge, or both.
• Edge detection is asynchronous, so it may operate when clocks are not present, such
as during Power-down mode. With this feature, level triggered interrupts are not
needed.
• Each enabled interrupt contributes to a wake-up signal that can be used to bring the
part out of Power-down mode.
UM10360
Chapter 9: LPC176x/5x General Purpose Input/Output (GPIO)
Rev. 3 — 19 December 2013 User manual
