UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 425 of 841
NXP Semiconductors
UM10360
Chapter 18: LPC176x/5x SSP0/1
18.6.4 SSPn Status Register (SSP0SR - 0x4008 800C, SSP1SR -
0x4003 000C)
This read-only register reflects the current status of the SSP controller.
18.6.5 SSPn Clock Prescale Register (SSP0CPSR - 0x4008 8010, SSP1CPSR
- 0x4003 0010)
This register controls the factor by which the Prescaler divides the SSP peripheral clock
SSP_PCLK to yield the prescaler clock that is, in turn, divided by the SCR factor in
SSPnCR0, to determine the bit clock.
Important: the SSPnCPSR value must be properly initialized or the SSP controller will not
be able to transmit data correctly.
In Slave mode, the SSP clock rate provided by the master must not exceed 1/12 of the
SSP peripheral clock selected in Section 4.7.3
. The content of the SSPnCPSR register is
not relevant.
In master mode, CPSDVSR
min
= 2 or larger (even numbers only).
18.6.6 SSPn Interrupt Mask Set/Clear Register (SSP0IMSC - 0x4008 8014,
SSP1IMSC - 0x4003 0014)
This register controls whether each of the four possible interrupt conditions in the SSP
controller are enabled. Note that ARM uses the word “masked” in the opposite sense from
classic computer terminology, in which “masked” meant “disabled”. ARM uses the word
“masked” to mean “enabled”. To avoid confusion we will not use the word “masked”.
Table 373: SSPn Status Register (SSP0SR - address 0x4008 800C, SSP1SR - 0x4003 000C)
bit description
Bit Symbol Description Reset
Value
0 TFE Transmit FIFO Empty. This bit is 1 is the Transmit FIFO is empty, 0 if not. 1
1 TNF Transmit FIFO Not Full. This bit is 0 if the Tx FIFO is full, 1 if not. 1
2 RNE Receive FIFO Not Empty. This bit is 0 if the Receive FIFO is empty, 1 if
not.
0
3 RFF Receive FIFO Full. This bit is 1 if the Receive FIFO is full, 0 if not. 0
4 BSY Busy. This bit is 0 if the SSPn controller is idle, or 1 if it is currently
sending/receiving a frame and/or the Tx FIFO is not empty.
0
31:5 - Reserved, user software should not write ones to reserved bits. The
value read from a reserved bit is not defined.
NA
Table 374: SSPn Clock Prescale Register (SSP0CPSR - address 0x4008 8010, SSP1CPSR -
0x4003 0010) bit description
Bit Symbol Description Reset
Value
7:0 CPSDVSR This even value between 2 and 254, by which SSP_PCLK is divided
to yield the prescaler output clock. Bit 0 always reads as 0.
0
31:8 - Reserved, user software should not write ones to reserved bits. The
value read from a reserved bit is not defined.
NA
