UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 226 of 841
NXP Semiconductors
UM10360
Chapter 11: LPC176x/5x USB device controller
11.10.2.5 USB Device Interrupt Set register (USBDevIntSet - 0x5000 C20C)
Writing one to a bit in this register sets the corresponding bit in the USBDevIntSt. Writing a
zero has no effect
USBDevIntSet is a write-only register.
Table 196. USB Device Interrupt Clear register (USBDevIntClr - address 0x5000 C208) bit allocation
Reset value: 0x0000 0000
Bit 31 30 29 28 27 26 25 24
Symbol
--------
Bit 23 22 21 20 19 18 17 16
Symbol
--------
Bit 15 14 13 12 11 10 9 8
Symbol
------ERR_INTEP_RLZED
Bit 7 6 5 4 3 2 1 0
Symbol
TxENDPKT Rx
ENDPKT
CDFULL CCEMPTY DEV_STAT EP_SLOW EP_FAST FRAME
Table 197. USB Device Interrupt Clear register (USBDevIntClr - address 0x5000 C208) bit description
Bit Symbol Value Description Reset value
31:0 See
USBDevIntClr
bit allocation
table above
0 No effect. 0
1 The corresponding bit in USBDevIntSt (Section 11.10.2.2
) is cleared.
Table 198. USB Device Interrupt Set register (USBDevIntSet - address 0x5000 C20C) bit allocation
Reset value: 0x0000 0000
Bit 31 30 29 28 27 26 25 24
Symbol
--------
Bit 23 22 21 20 19 18 17 16
Symbol
--------
Bit 15 14 13 12 11 10 9 8
Symbol
------ERR_INTEP_RLZED
Bit 7 6 5 4 3 2 1 0
Symbol
TxENDPKT Rx
ENDPKT
CDFULL CCEMPTY DEV_STAT EP_SLOW EP_FAST FRAME
Table 199. USB Device Interrupt Set register (USBDevIntSet - address 0x5000 C20C) bit description
Bit Symbol Value Description Reset value
31:0 See
USBDevIntSet
bit allocation
table above
0 No effect. 0
1 The corresponding bit in USBDevIntSt (Section 11.10.2.2
) is set.
