UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 497 of 841
NXP Semiconductors
UM10360
Chapter 21: LPC176x/5x Timer 0/1/2/3
21.6.7 Match Registers (MR0 - MR3)
The Match register values are continuously compared to the Timer Counter value. When
the two values are equal, actions can be triggered automatically. The action possibilities
are to generate an interrupt, reset the Timer Counter, or stop the timer. Actions are
controlled by the settings in the MCR register.
21.6.8 Match Control Register (T[0/1/2/3]MCR - 0x4000 4014, 0x4000 8014,
0x4009 0014, 0x4009 4014)
The Match Control Register is used to control what operations are performed when one of
the Match Registers matches the Timer Counter. The function of each of the bits is shown
in Table 429
.
Table 429. Match Control Register (T[0/1/2/3]MCR - addresses 0x4000 4014, 0x4000 8014, 0x4009 0014, 0x4009 4014)
bit description
Bit Symbol Value Description Reset
Value
0 MR0I 1 Interrupt on MR0: an interrupt is generated when MR0 matches the value in the TC. 0
0 This interrupt is disabled
1 MR0R 1 Reset on MR0: the TC will be reset if MR0 matches it. 0
0 Feature disabled.
2 MR0S 1 Stop on MR0: the TC and PC will be stopped and TCR[0] will be set to 0 if MR0 matches
the TC.
0
0 Feature disabled.
3 MR1I 1 Interrupt on MR1: an interrupt is generated when MR1 matches the value in the TC. 0
0 This interrupt is disabled
4 MR1R 1 Reset on MR1: the TC will be reset if MR1 matches it. 0
0 Feature disabled.
5 MR1S 1 Stop on MR1: the TC and PC will be stopped and TCR[0] will be set to 0 if MR1 matches
the TC.
0
0 Feature disabled.
6 MR2I 1 Interrupt on MR2: an interrupt is generated when MR2 matches the value in the TC. 0
0 This interrupt is disabled
7 MR2R 1 Reset on MR2: the TC will be reset if MR2 matches it. 0
0 Feature disabled.
8 MR2S 1 Stop on MR2: the TC and PC will be stopped and TCR[0] will be set to 0 if MR2 matches
the TC.
0
0 Feature disabled.
9 MR3I 1 Interrupt on MR3: an interrupt is generated when MR3 matches the value in the TC. 0
0 This interrupt is disabled
10 MR3R 1 Reset on MR3: the TC will be reset if MR3 matches it. 0
0 Feature disabled.
11 MR3S 1 Stop on MR3: the TC and PC will be stopped and TCR[0] will be set to 0 if MR3 matches
the TC.
0
0 Feature disabled.
31:12 - Reserved, user software should not write ones to reserved bits. The value read from a
reserved bit is not defined.
NA
