UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 20 December 2013 692 of 841
NXP Semiconductors
UM10360
Chapter 34: Appendix: Cortex-M3 user guide
34.2.5.9 TST and TEQ
Test bits and Test Equivalence.
34.2.5.9.1 Syntax
TST
{cond} Rn, Operand2
TEQ
{cond} Rn, Operand2
where:
cond is an optional condition code, see Section 34.2.3.7 “
Conditional execution”.
Rn is the register holding the first operand.
Operand2 is a flexible second operand. See Section 34.2.3.3
for details of the options.
34.2.5.9.2 Operation
These instructions test the value in a register against Operand2. They update the
condition flags based on the result, but do not write the result to a register.
The
TST
instruction performs a bitwise AND operation on the value in Rn and the value of
Operand2. This is the same as the
ANDS
instruction, except that it discards the result.
To test whether a bit of Rn is 0 or 1, use the
TST
instruction with an Operand2 constant that
has that bit set to 1 and all other bits cleared to 0.
The
TEQ
instruction performs a bitwise Exclusive OR operation on the value in Rn and the
value of Operand2. This is the same as the
EORS
instruction, except that it discards the
result.
Use the
TEQ
instruction to test if two values are equal without affecting the V or C flags.
TEQ
is also useful for testing the sign of a value. After the comparison, the N flag is the
logical Exclusive OR of the sign bits of the two operands.
34.2.5.9.3 Restrictions
Do not use SP and do not use PC.
34.2.5.9.4 Condition flags
These instructions:
• update the N and Z flags according to the result
• can update the C flag during the calculation of Operand2, see Section 34.2.3.3
• do not affect the V flag.
34.2.5.9.5 Examples
TST R0, #0x3F8 ; Perform bitwise AND of R0 value to 0x3F8,
; APSR is updated but result is discarded
TEQEQ R10, R9 ; Conditionally test if value in R10 is equal to
; value in R9, APSR is updated but result is discarded
