UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 8 of 841
NXP Semiconductors
UM10360
Chapter 1: LPC176x/5x Introductory information
1.4 Ordering information
1.4.1 Part options summary
Table 1. Ordering information
Type number Package
Name Description Version
LPC1769FBD100
LQFP100 plastic low profile quad flat package; 100 leads; body 14 ï‚´ 14 ï‚´ 1.4 mm SOT407-1
LPC1768FBD100
LPC1767FBD100
LPC1766FBD100
LPC1765FBD100
LPC1764FBD100
LPC1763FBD100
LPC1768FET100 TFBGA100 plastic thin fine-pitch ball grid array package; 100 balls; body 9 x 9 x 0.7 mm SOT926-1
LPC1759FBD80
LQFP80 plastic low profile quad flat package; 80 leads; body 12 ï‚´ 12ï€ ï‚´ 1.4 mm SOT315-1
LPC1758FBD80
LPC1756FBD80
LPC1754FBD80
LPC1752FBD80
LPC1751FBD80
Table 2. Ordering options for LPC176x/5x parts
Type number Max. CPU
speed
Flash Total
SRAM
Ethernet USB CAN I
2
S DAC Package
LPC1769FBD100 120 MHz 512 kB 64 kB yes Device/Host/OTG 2 yes yes 100 pin
LPC1768FBD100 100 MHz 512 kB 64 kB yes Device/Host/OTG 2 yes yes 100 pin
LPC1768FET100 100 MHz 512 kB 64 kB yes Device/Host/OTG 2 yes yes 100 pin
LPC1767FBD100 100 MHz 512 kB 64 kB yes no no yes yes 100 pin
LPC1766FBD100 100 MHz 256 kB 64 kB yes Device/Host/OTG 2 yes yes 100 pin
LPC1765FBD100 100 MHz 256 kB 64 kB no Device/Host/OTG 2 yes yes 100 pin
LPC1764FBD100 100 MHz 128 kB 32 kB yes Device 2 no no 100 pin
LPC1763FBD100 100 MHz 256 kB 64 kB no no no yes yes 100 pin
LPC1759FBD80 120 MHz 512 kB 64 kB no Device/Host/OTG 2 yes yes 80 pin
LPC1758FBD80 100 MHz 512 kB 64 kB yes Device/Host/OTG 2 yes yes 80 pin
LPC1756FBD80 100 MHz 256 kB 32 kB no Device/Host/OTG 2 yes yes 80 pin
LPC1754FBD80 100 MHz 128 kB 32 kB no Device/Host/OTG 1 no yes 80 pin
LPC1752FBD80 100 MHz 64 kB 16 kB no Device 1 no no 80 pin
LPC1751FBD80 100 MHz 32 kB 8 kB no Device 1 no no 80 pin
