UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 291 of 841
NXP Semiconductors
UM10360
Chapter 13: LPC176x/5x USB OTG
/* Wait for TDI to be set */
while (!(OTG_I2C_STS & TDI));
/* Clear TDI */
OTG_I2C_STS = TDI;
Add D+ pull-up
/* Add D+ pull-up through ISP1302 */
OTG_I2C_TX = 0x15A; // Send ISP1302 address, R/W=0
OTG_I2C_TX = 0x006; // Send OTG Control (Set) register address
OTG_I2C_TX = 0x201; // Set DP_PULLUP bit, send STOP condition
/* Wait for TDI to be set */
while (!(OTG_I2C_STS & TDI));
/* Clear TDI */
OTG_I2C_STS = TDI;
13.9.2 A-device: host to peripheral HNP switching
In this case, the role of the OTG controller is host (A-device), and the A-device switches
roles from host to peripheral.
The On-The-Go Supplement defines the behavior of a dual-role A-device during HNP
using a state machine diagram. The OTG software stack is responsible for implementing
all of the states in the Dual-Role A-Device State Diagram.
The OTG controller hardware provides support for the state transitions between a_host,
a_suspend, a_wait_vfall, and a_peripheral in the Dual-Role A-Device state diagram.
Setting A_HNP_TRACK in the OTGStCtrl register enables hardware support for switching
the A-device from the host state to the device state. The hardware actions after setting
this bit are shown in Figure 42
.
