Chapter 8: LPC176x/5x Pin connect block
[1] Not available on 80-pin package.
8.5.13 Pin Mode select register 4 (PINMODE4 - 0x4002 C050)
This register controls pull-up/pull-down resistor configuration for Port 2 pins 0 to 15. For
details see Section 8.4 “
Pin mode select register values.
[1] Not available on 80-pin package.
15:14 P1.23MODE Port 1 pin 23 control, see P0.00MODE. 00
17:16 P1.24MODE Port 1 pin 24 control, see P0.00MODE. 00
19:18 P1.25MODE Port 1 pin 25 control, see P0.00MODE. 00
21:20 P1.26MODE Port 1 pin 26 control, see P0.00MODE. 00
23:22 P1.27MODE
[1]
Port 1 pin 27 control, see P0.00MODE. 00
25:24 P1.28MODE Port 1 pin 28 control, see P0.00MODE. 00
27:26 P1.29MODE Port 1 pin 29 control, see P0.00MODE. 00
29:28 P1.30MODE Port 1 pin 30 control, see P0.00MODE. 00
31:30 P1.31MODE Port 1 pin 31 control, see P0.00MODE. 00
Table 90. Pin Mode select register 3 (PINMODE3 - address 0x4002 C04C) bit description
PINMODE3 Symbol Description Reset
value
Table 91. Pin Mode select register 4 (PINMODE4 - address 0x4002 C050) bit description
PINMODE4 Symbol Description Reset
value
1:0 P2.00MODE Port 2 pin 0 control, see P0.00MODE. 00
3:2 P2.01MODE Port 2 pin 1 control, see P0.00MODE. 00
5:4 P2.02MODE Port 2 pin 2 control, see P0.00MODE. 00
7:6 P2.03MODE Port 2 pin 3 control, see P0.00MODE. 00
9:8 P2.04MODE Port 2 pin 4 control, see P0.00MODE. 00
11:10 P2.05MODE Port 2 pin 5 control, see P0.00MODE. 00
13:12 P2.06MODE Port 2 pin 6 control, see P0.00MODE. 00
15:14 P2.07MODE Port 2 pin 7 control, see P0.00MODE. 00
17:16 P2.08MODE Port 2 pin 8 control, see P0.00MODE. 00
19:18 P2.09MODE Port 2 pin 9 control, see P0.00MODE. 00
21:20 P2.10MODE Port 2 pin 10 control, see P0.00MODE. 00
23:22 P2.11MODE
[1]
Port 2 pin 11 control, see P0.00MODE. 00
25:24 P2.12MODE
[1]
Port 2 pin 12 control, see P0.00MODE. 00
27:26 P2.13MODE
[1]
Port 2 pin 13 control, see P0.00MODE. 00
31:28 - Reserved. NA
