Page #528 background image
UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 528 of 841
NXP Semiconductors
UM10360
Chapter 25: LPC176x/5x Motor control PWM
25.7.1.2 MCPWM Control set address (MCCON_SET - 0x400B 8004)
Writing ones to this write-only address sets the corresponding bits in MCCON.
15:13 - - Reserved. 0
16 RUN2 Stops/starts timer channel 2. 0
0Stop.
1Run.
17 CENTER2 Edge/center aligned operation for channel 2. 0
0 Edge-aligned.
1 Center-aligned.
18 POLA2 Selects polarity of the MCOA2 and MCOB2 pins. 0
0 Passive state is LOW, active state is HIGH.
1 Passive state is HIGH, active state is LOW.
19 DTE2 Controls the dead-time feature for channel 1. 0
0 Dead-time disabled.
1 Dead-time enabled.
20 DISUP2 Enable/disable updates of functional registers for channel 2 (see Section 25.8.2
,
Section 25.7.6.1
).
0
0 Functional registers are updated from the write registers at the end of each PWM
cycle.
1 Functional registers remain the same as long as the timer is running.
28:21 - - Reserved.
29 INVBDC Controls the polarity of the MCOB outputs for all 3 channels. This bit is typically set
to 1 only in 3-phase DC mode.
0 The MCOB outputs have opposite polarity from the MCOA outputs (aside from
dead time).
1 The MCOB outputs have the same basic polarity as the MCOA outputs. (see
Section 25.8.6
)
30 ACMODE 3-phase AC mode select (see Section 25.8.7
). 0
0 3-phase AC-mode off: Each PWM channel uses its own timer-counter and period
register.
1 3-phase AC-mode on: All PWM channels use the timer-counter and period register
of channel 0.
31 DCMODE 3-phase DC mode select (see Section 25.8.6
). 0
0 3-phase DC mode off: PWM channels are independent (unless bit ACMODE = 1)
1 3-phase DC mode on: The internal MCOA0 output is routed through the MCCP (i.e.
a mask) register to all six PWM outputs.
Table 455. MCPWM Control read address (MCCON - 0x400B 8000) bit description …continued
Bit Symbol Value Description Reset
value
Table 456. MCPWM Control set address (MCCON_SET - 0x400B 8004) bit description
Bit Description
31:0 Writing ones to this address sets the corresponding bits in the MCCON register. See Table 455.
