Chapter 32: LPC176x/5x Flash memory interface and programming
32.5 Sector numbers
Some IAP and ISP commands operate on "sectors" and specify sector numbers. The
following table indicate the correspondence between sector numbers and memory
addresses for LPC176x/5x devices containing 32, 64, 128, 256 and 512 kB of flash
respectively. IAP and ISP routines are located in the Boot ROM.
Table 567. Sectors in a LPC176x/5x device
Sector
Number
Sector
Size [kB]
Start Address End Address 32 kB
Part
64 kB
Part
128 kB
Part
256 kB
Part
512 kB
Part
0 4 0X0000 0000 0X0000 0FFF x x x x x
1 4 0X0000 1000 0X0000 1FFF x x x x x
2 4 0X0000 2000 0X0000 2FFF x x x x x
3 4 0X0000 3000 0X0000 3FFF x x x x x
4 4 0X0000 4000 0X0000 4FFF x x x x x
5 4 0X0000 5000 0X0000 5FFF x x x x x
6 4 0X0000 6000 0X0000 6FFF x x x x x
7 4 0X0000 7000 0X0000 7FFF x x x x x
8 4 0x0000 8000 0X0000 8FFF x x x x
9 4 0x0000 9000 0X0000 9FFF x x x x
10 (0x0A) 4 0x0000 A000 0X0000 AFFF x x x x
11 (0x0B) 4 0x0000 B000 0X0000 BFFF x x x x
12 (0x0C) 4 0x0000 C000 0X0000 CFFF x x x x
13 (0x0D) 4 0x0000 D000 0X0000 DFFF x x x x
14 (0X0E) 4 0x0000 E000 0X0000 EFFF x x x x
15 (0x0F) 4 0x0000 F000 0X0000 FFFF x x x x
16 (0x10) 32 0x0001 0000 0x0001 7FFF x x x
17 (0x11) 32 0x0001 8000 0x0001 FFFF x x x
18 (0x12) 32 0x0002 0000 0x0002 7FFF x x
19 (0x13) 32 0x0002 8000 0x0002 FFFF x x
20 (0x14) 32 0x0003 0000 0x0003 7FFF x x
21 (0x15) 32 0x0003 8000 0x0003 FFFF x x
22 (0x16) 32 0x0004 0000 0x0004 7FFF x
23 (0x17) 32 0x0004 8000 0x0004 FFFF x
24 (0x18) 32 0x0005 0000 0x0005 7FFF x
25 (0x19) 32 0x0005 8000 0x0005 FFFF x
26 (0x1A) 32 0x0006 0000 0x0006 7FFF x
27 (0x1B) 32 0x0006 8000 0x0006 FFFF x
28 (0x1C) 32 0x0007 0000 0x0007 7FFF x
29 (0x1D) 32 0x0007 8000 0x0007 FFFF x
