UM10360 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2013. All rights reserved.
User manual Rev. 3 — 19 December 2013 75 of 841
NXP Semiconductors
UM10360
Chapter 6: LPC176x/5x Nested Vectored Interrupt Controller (NVIC)
14 30 0x78 SSP0 Tx FIFO half empty of SSP0
Rx FIFO half full of SSP0
Rx Timeout of SSP0
Rx Overrun of SSP0
15 31 0x7C SSP 1 Tx FIFO half empty
Rx FIFO half full
Rx Timeout
Rx Overrun
16 32 0x80 PLL0 (Main PLL) PLL0 Lock (PLOCK0)
17 33 0x84 RTC Counter Increment (RTCCIF)
Alarm (RTCALF)
18 34 0x88 External Interrupt External Interrupt 0 (EINT0)
19 35 0x8C External Interrupt External Interrupt 1 (EINT1)
20 36 0x90 External Interrupt External Interrupt 2 (EINT2)
21 37 0x94 External Interrupt External Interrupt 3 (EINT3).
Note: EINT3 channel is shared with GPIO interrupts
22 38 0x98 ADC A/D Converter end of conversion
23 39 0x9C BOD Brown Out detect
24 40 0xA0 USB USB_INT_REQ_LP, USB_INT_REQ_HP, USB_INT_REQ_DMA
25 41 0xA4 CAN CAN Common, CAN 0 Tx, CAN 0 Rx, CAN 1 Tx, CAN 1 Rx
26 42 0xA8 GPDMA IntStatus of DMA channel 0, IntStatus of DMA channel 1
27 43 0xAC I
2
S irq, dmareq1, dmareq2
28 44 0xB0 Ethernet WakeupInt, SoftInt, TxDoneInt, TxFinishedInt, TxErrorInt,
TxUnderrunInt, RxDoneInt, RxFinishedInt, RxErrorInt,
RxOverrunInt.
29 45 0xB4 Repetitive Interrupt
Timer
RITINT
30 46 0xB8 Motor Control PWM IPER[2:0], IPW[2:0], ICAP[2:0], FES
31 47 0xBC Quadrature Encoder INX_Int, TIM_Int, VELC_Int, DIR_Int, ERR_Int, ENCLK_Int,
POS0_Int, POS1_Int, POS2_Int, REV_Int, POS0REV_Int,
POS1REV_Int, POS2REV_Int
32 48 0xC0 PLL1 (USB PLL) PLL1 Lock (PLOCK1)
33 49 0xC4 USB Activity Interrupt USB_NEED_CLK
34 50 0xC8 CAN Activity Interrupt CAN1WAKE, CAN2WAKE
Table 50. Connection of interrupt sources to the Vectored Interrupt Controller
Interrupt
ID
Exception
Number
Vector
Offset
Function Flag(s)
