5-804-111 Fusing Fan: Half Speed ENG [0 or 1 / 0 / 1/step]
Moves fusing exhaust fan.
5-804-113 PSU Cooling/Exhaust Heat Fan ENG [0 or 1 / 0 / 1/step]
Moves PSU cooling fan and PSU exhaust fan (not included in this machine).
5-804-114 Ozone Fan ENG [0 or 1 / 0 / 1/step]
Moves ozone exhaust heat fan.
5-804-115 PCB Box Cooling Fan/ Exhaust
Cooling Fan
ENG [0 or 1 / 0 / 1/step]
Moves controller box cooling fan and exhaust cooling fan.
5-804-116 Development: Right: Half
Speed
ENG [0 or 1 / 0 / 1/step]
Moves development intake fan.
5-804-117 Drive Cooling/ Main/ Toner
Supply Cooling Fan
ENG [0 or 1 / 0 / 1/step]
Moves drive cooling fan (not included in this machine), main exhaust fan (not
included in this machine), and toner supply cooling fan.
5-804-118 Development: Right ENG [0 or 1 / 0 / 1/step]
Moves development intake fan.
5-804-119 Development Solenoid ENG [0 or 1 / 0 / 1/step]
Moves development solenoid.
5804 [OUTPUT Check]
Moves development motor.
5-804-128 Development Motor FC:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-130 Development Motor FC: Low
Speed
ENG
Input and Output Check
481
