5804 [OUTPUT Check]
Moves/Stops PCU motor :CMY.
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-132 Drum Motor FC: Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-134 Drum Motor FC: Low Speed ENG
5804 [OUTPUT Check]
Moves/Stops PCU motor: Black/ ITB drive motor.
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-136 Transfer Drum Motor K:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-138 Transfer Drum Motor K: Low
Speed
ENG
5804 [OUTPUT Check]
Moves paper transfer contact and release motor.
5-804-140 PTR Contact Motor:CW ENG [0 or 1 / 0 / 1/step]
5-804-141 PTR Contact Motor:CCW ENG
5804 [OUTPUT Check]
Moves ITB contact and release motor (reverse to toner supply motor M).
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-150 Toner Supply Motor M:CW:
(ITB Contact)
ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
Moves relay carry motor (bridge unit)/left paper exit carry motor (left paper exit
tray).
3. Engine SP Mode Tables
482
