5-804-163 Bridge Relay/Left Exit Motor:
Normal Speed
ENG [0 or 1 / 0 / 1/step]
5-804-165 Bridge Relay/Left Exit Motor:
Low Speed
ENG
5-804-166 Bridge Relay/Left Ex Mt:
Normal Speed Upper
ENG
5804 [OUTPUT Check]
5-804-169 Bridge Junction/Left Exit
Junction Solenoid
ENG [0 or 1 / 0 / 1/step]
Moves relay divide solenoid (bridge unit)/left paper exit divide solenoid (left paper
exit tray).
5-804-170 Shift Tray Motor:CW ENG [0 or 1 / 0 / 1/step]
Moves shift tray motor.
5-804-171 Shift Tray Motor:CCW ENG [0 or 1 / 0 / 1/step]
Moves shift tray motor.
5-804-172 Toner End Sensor: K Power ENG [0 or 1 / 0 / 1/step]
Supples power to toner end sensor (K).
5-804-173 Toner End Sensor: FC Power ENG [0 or 1 / 0 / 1/step]
Supples power to toner end sensor (FC).
5-804-174 Drum PCL: K ENG [0 or 1 / 0 / 1/step]
Lights (PWM drive) the drum PCL (K).
* Continuing the OPC's exposure, it might accumulate damage due to electrostatic
locally.
• If operating QL without rotation, be sure to stop it within 10 seconds.
• Do rotate the OPC drum when QL is turned on.
