5-804-175 Drum PCL: FC ENG [0 or 1 / 0 / 1/step]
Lights (PWM drive) the drum PCL (FC).
* Continuing the OPC's exposure, it might accumulate damage due to electrostatic
locally.
• If operating QL without rotation, be sure to stop it within 10 seconds.
• Do rotate the OPC drum when QL is turned on.
5804 [OUTPUT Check]
Outputs PWM for electrify HVP (DC/AC:Y/M/C/K).
5-804-176 PP: Charge DC: Y ENG [0 or 1 / 0 / 1/step]
5-804-177 PP: Charge DC: M ENG
5-804-178 PP: Charge DC: C ENG
5-804-179 PP: Charge DC: K ENG
5-804-180 PP: Charge AC: Y ENG
[0 or 1 / 0 / 1/step]
This setting is not available for MP
C2004/MP C2504
5-804-181 PP: Charge AC: M ENG
5-804-182 PP: Charge AC: C ENG
5-804-183 PP: Charge AC: K ENG
5804 [OUTPUT Check]
Outputs PWM for develop HVP.
5-804-184 PP: Development: Y ENG [0 or 1 / 0 / 1/step]
5-804-185 PP: Development: M ENG
5-804-186 PP: Development: C ENG
5-804-187 PP: Development: K ENG
5804 [OUTPUT Check]
Outputs PWM for transfer HVP (image transfer: Y/M/C/K).
3. Engine SP Mode Tables
484
