5-804-195 PP: ITB: Y ENG [0 or 1 / 0 / 1/step]
5-804-196 PP: ITB: M ENG
5-804-197 PP: ITB: C ENG
5-804-198 PP: ITB: K ENG
5804 [OUTPUT Check]
Outputs PWM for transfer HVP (paper transfer: +/-).
5-804-199 PP: PTR: + ENG [0 or 1 / 0 / 1/step]
5-804-200 PP: PTR: - ENG
5804 [OUTPUT Check]
5-804-202 Scanner Lamp ENG [0 or 1 / 0 / 1/step]
Checks output of scanner lamp.
Use to check light source malfunction when SC101-01, SC101-02, SC102-00,
SC142-00 occurs.
5-804-206 PTR Open/Close LED ENG [0 or 1 / 0 / 1/step]
Lights paper transfer open/close LED.
5-804-208 TM/P Sensor: F ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Front glowing part.
5-804-209 TM/P Sensor: C ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Center glowing part.
5-804-210 TM/P Sensor: R ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Rear glowing part.
5-804-211 Toner Sensor Power ENG [0 or 1 / 0 / 1/step]
5-804-232 Toner IDTAG Power ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
5-804-239 Fusing Exit Drive Solenoid ENG [0 or 1 / 0 / 1/step]
Input and Output Check
485
