5804 [OUTPUT Check]
Continuously drives specified motor for operation test.
5-804-241 Bank: Tray3: Feed Mt:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-242 Bank: Tray4: Feed Mt:
Standard Speed
ENG
5-804-243 Bank: Tray5: Feed Mt:
Standard Speed
ENG
5-804-244 Bank: Tray3: Transport Mt:
Standard Speed
ENG
5-804-245 Bank: Tray4: Transport Mt:
Standard Speed
ENG
5-804-246 Bank: Tray5: Transport Mt:
Standard Speed
ENG
5804 [OUTPUT Check]
Drives specified motor for a certain period of time to test operation.
5-804-247 Bank: Tray3: PU Solenoid ENG [0 or 1 / 0 / 1/step]
5-804-248 Bank: Tray4: PU Solenoid ENG
5-804-249 Bank: Tray5: PU Solenoid ENG
ADF
6008 [ADF OUTPUT Check]
Checks operation of the load of ADF.
6-008-003 Feed Motor Forward ENG [0 or 1 / 0 / 1/step]
Rotates paper feed motor forward.
6-008-004 Feed Motor Reverse ENG [0 or 1 / 0 / 1/step]
Rotates paper feed motor backward.
3. Engine SP Mode Tables
486
