6-008-005 Relay Motor Forward ENG [0 or 1 / 0 / 1/step]
Rotates carry motor forward.
6-008-006 Relay Motor Reverse ENG [0 or 1 / 0 / 1/step]
Rotates carry motor backward.
6-008-011 Inverter Solenoid ENG [0 or 1 / 0 / 1/step]
Interval drives reverse solenoid.
6-008-012 Stamp ENG [0 or 1 / 0 / 1/step]
Interval drives DONE stamp.
6-008-013 Fan Motor ENG [0 or 1 / 0 / 1/step]
Interval drives FAN motor.
6-008-014 Feed Clutch ENG [0 or 1 / 0 / 1/step]
Interval drives paper feed clutch.
6-008-015 Feed Solenoid ENG [0 or 1 / 0 / 1/step]
Interval drives paper feed solenoid.
6012 [1-Pass ADF OUTPUT Check]
For Single-Pass simultaneous duplex models only.
6-012-001 Pick-Up Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF pick up motor.
6-012-003 Feed Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF paper feed motor.
Input and Output Check
487
