6-012-005 Relay Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF paper carry motor.
6-012-009 Exit Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF paper exit motor.
6-012-010 Bottom Plate Motor For/Rev ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Moves up/down the bottom plate by driving the ADF bottom plate motor forward,
backward.
6-012-012 Stamp ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Stamps the DONE stamp.
6-012-015 Pull-Out Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF pull out motor.
6-012-016 Middle Motor Forward ENG [0 or 1 / 0 / 1/step]
0:Off
1:On
Forwardly rotates ADF middle motor.
Finisher
6124 [OUTPUT Check: 2K/3K FIN]
3. Engine SP Mode Tables
488
