6136 [OUTPUT Check: FrontFIN]
Continuously drives specified motor for operation test.
6-136-001 Entrance Motor *ENG [0 or 1 / 0 / 1/step]
6-136-002 Carry Motor ENG [0 or 1 / 0 / 1/step]
6-136-003 Exit Motor ENG [0 or 1 / 0 / 1/step]
6136 [OUTPUT Check: FrontFIN]
Drives specified motor for a certain period of time to test operation.
6-136-004 Front Jogger Motor ENG [0 or 1 / 0 / 1/step]
6-136-005 Rear Jogger Motor ENG [0 or 1 / 0 / 1/step]
6-136-006 Shift Motor ENG [0 or 1 / 0 / 1/step]
6-136-007 Hitroll Motor ENG [0 or 1 / 0 / 1/step]
6-136-008 Exit Guide Plate Motor ENG [0 or 1 / 0 / 1/step]
6-136-009 Staple Moving Motor ENG [0 or 1 / 0 / 1/step]
6-136-010 Tray Motor ENG [0 or 1 / 0 / 1/step]
6-136-011 Staple Motor ENG [0 or 1 / 0 / 1/step]
6-136-012 Stopper Motor ENG [0 or 1 / 0 / 1/step]
6-136-013 Punch Motor ENG [0 or 1 / 0 / 1/step]
6-136-014 Punch Moving Motor ENG [0 or 1 / 0 / 1/step]
6-136-015 Punch Registration Moving
Motor
ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Continuously runs specified motor for operation test.
6-162-001 Entrance Transport Motor ENG [0 or 1 / 0 / 1/step]
6-162-002 Proof Transport Motor ENG [0 or 1 / 0 / 1/step]
6-162-003 Paper Feed/Positioning &
Move Roller Motor
ENG [0 or 1 / 0 / 1/step]
3. Engine SP Mode Tables
492
