6162 [FIN (1K FIN) OUTPUT Check]
Drives specified motor for a certain period of time to test operation.
6-162-004 Junction Solenoid ENG [0 or 1 / 0 / 1/step]
6-162-005 Shift Motor ENG [0 or 1 / 0 / 1/step]
6-162-006 Jogger Motor ENG [0 or 1 / 0 / 1/step]
6-162-007 Exit Guide Plate Open/
Close Motor
ENG [0 or 1 / 0 / 1/step]
6-162-008 Feed-out Motor ENG [0 or 1 / 0 / 1/step]
6-162-009 Tray Lift Motor ENG [0 or 1 / 0 / 1/step]
6-162-011 Positioning Roller Motor ENG [0 or 1 / 0 / 1/step]
6-162-012 Stapler Shift Motor ENG [0 or 1 / 0 / 1/step]
6-162-013 Stapler Motor ENG [0 or 1 / 0 / 1/step]
6-162-014 Untitled ENG [0 or 1 / 0 / 1/step]
6-162-015 Untitled ENG [0 or 1 / 0 / 1/step]
6-162-016 Untitled ENG [0 or 1 / 0 / 1/step]
6-162-017 Punch Motor ENG [0 or 1 / 0 / 1/step]
6-162-018 Punch Move Motor ENG [0 or 1 / 0 / 1/step]
6-162-019 S-to-S Registration
Detection Move Motor
ENG [0 or 1 / 0 / 1/step]
6-162-020 Stack Transport Motor:
Upper
ENG [0 or 1 / 0 / 1/step]
6-162-021 Stck Trns Uppr Prss Rls/
Stndrd Fence Rtrct M
ENG [0 or 1 / 0 / 1/step]
6-162-022 Stack Lower Pressure
Release Motor
ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Continuously runs specified motor for operation test.
6-162-023 Folder Transport Motor ENG [0 or 1 / 0 / 1/step]
Input and Output Check
493
