6162 [FIN (1K FIN) OUTPUT Check]
Drives specified motor for a certain period of time to test operation.
6-162-024 TE Stopper Motor ENG [0 or 1 / 0 / 1/step]
6-162-025 Folder Blade Motor ENG [0 or 1 / 0 / 1/step]
6162 [FIN (1K FIN) OUTPUT Check]
Lights all guide LED.
6-162-026 Navigation LED (All) ENG [0 or 1 / 0 / 1/step]
6185 [Output Check: NoStplBindFIN]
6-185-001 Transport Motor ENG [0 or 1 / 0 / 1/step]
Checks the transport motor’s movement of non staple finisher.
6-185-002 Shift Motor ENG [0 or 1 / 0 / 1/step]
Checks the shift motor’s movement of non staple finisher.
6-185-003 Junction Solenoid Motor ENG [0 or 1 / 0 / 1/step]
Checks the junction solenoid motor’s movement of non staple finisher.
6-185-004 Exit Pressure Release
Motor
ENG [0 or 1 / 0 / 1/step]
Checks the exit pressure release motor’s movement of non staple finisher.
6-185-005 Stapler Motor ENG [0 or 1 / 0 / 1/step]
Checks the stapler motor’s movement of non staple finisher.
3. Engine SP Mode Tables
494

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
