1-004-002 Print Summary2 *CTL [- / - / -]
[Execute]
1005 [Display Version]
1-005-002 Printer Version *CTL [ - / - / - ]
Displays the version of the controller firmware.
1006 [Sample / Proof Print]
1-006-001 Sample / Proof Print *CTL [0 or 1 / 1 / 1 /step]
0: Linked, 1: On
Enables and disables the document server. When you select "0," the document server
is enabled or disabled in accordance with Copy Service Mode SP5-967. When you
select "1," the document server is enabled regardless of Copy Service Mode
SP5-967.
1101 [Data Recall]
Recalls a set of gamma settings. This can be either a) the factory setting, b) the
previous setting, or c) the current setting.
1-101-001 Factory *CTL [ - / - / - ]
[Execute]
1-101-002 Previous *CTL
1-101-003 Current *CTL
1-101-004 ACC *CTL
1102 [Resolution Setting]
Selects the printing mode (resolution) for the printer gamma adjustment.
4. Controller SP Mode Tables
666
