10. Attach the relay guide plate [A] ( ×2).

11. Clean the right side of the upper cover with a cloth moistened with alcohol, and then

attach the cushion to the finisher.

• Make sure that the cushion is aligned with the front-lower edge [A] of the upper cover.

2. Installation

200
